23
rotor tip clearance.
SERVICE LIMMIT: 0.12 mm.
Remove the oil pump shaft and measure the
pump and clearance.
SERVICE LIMMIT: 0.2 mm.
4.5 OIL PUMP ASS’Y / INSTALLATION
Install the outer rotor, inner rotor and oil pump
shaft onto the body.
NOTE: Pour a drop of clean engine oil inside the
oil pump.
Install the oil pump ass’y
Install the oil pump driven sprocket and oil pump
