Aeon Overland-180 User Manual

3
1.3 SPECIFICATION
ENGINE 125 / 180
Type
Displacement
Bore and Stroke
Compression
Maximum Torque
Carburetor
Ignition
Starting
Lubrication
Air Cleaner
Transmission
CHASSIS
Overall Length
Overall Width
Overall Height
Seat Height
Wheel Base
Ground Clearance
Dry Weight
Fuel Tank Capacity
SUSPENSION
Front
Rear
BRAKES
Front
Rear
TIRES
Front
Rear




Specifications subject to change without notice.
Air-Cooled 4-syroke
with Oil Cooler
125 cc/169 cc
52.4×57.8mm/61×57.8mm
9.1:1
6.21 Nm@4017 rpm/10.24 Nm@4403 rpm
MIKUNI 125/180
Capacitor Discharge
Electrical & Kick-Start
Forced pressure
and wet sump
AE-9
Automatic(C.V.T. V-belt)
71.7 inches (1820mm)
38.4 inches (975mm)
41.7 inches (1060mm)
30.7 inches (675mm)
41.9 inches (1065mm)
6.5 inches (165mm)
166kg (365lb)
8.0 liter
Swing Axle
Swing Arm
Drum
Disc
21” × 7” - 10”
21” × 10” - 8”

