Aeon Overland-180 User Manual

45
7. TRANSMISSION & KICK STARTER
7.1 SERVUCE INFORMATION
7.2 TROUBLE SHOOTING
7.3 C.V.T DISASSEMBLY
7.4 KICK STARTER DISASSEMBLY
7.5 KICK STARTER ASSEMBLY
7.6 C.V.T ASSEMBLY
7.1 SERVICE INFORMATION
If the drain tube ass’y fills with water, the tube should be drained.
SPECIFICATIONS
ITEM STANDARD (mm) SERVICE LIMIT (mm)
Driven the width 19.8-20.2 19.0
Weight roller O.D. 15.0-15.02/17.0-17.02 14.6/16.6
Movable drive face I.D. 27.98-28.0 28.03
Drive face collar I.D. 24.06-24.09 24.098
Drive face boss O.D. 23.96-23.98 23.92
Clutch outer I.D. 124.8-125.2 125.5
