Aeon Overland-180 User Manual

49
Remove the drive face boss and movable driven face ass’y.
Remove the ramp plate and weight roller set.
Relax the special nut and remove the driven
plate composition and driven face spring.

Inspect the driven belt for wear, tears or damage.
Measure the width of driven belt.
SERVICE LIMIT:19.0 mm
DRIVE PULLEY FLANGE BELT
DRIVE FACE BOSS
MOVABLE DRIVEN FACE
