Removal and inspection.
Remove the rear wheel and the rear brake.
Remove the skid plate under swing arm.
Remove the drive chain cover.
Disassemble the chain retaining clips and mas-
ter link. Remove the chain.
Disassemble the driven sprocket, axle and
sprocket collar.
Check the driven sprocket for damage or wear.
Replace if necessary.
Let the rear axle lie in V-blocks and check the
runout.
The runout limit is 0.5 mm.
Check the turning of inner race of bearing with
fingers. The bearings should turn smoothly and
quietly. Replace if necessary.
