aerauliqa QD Series User Manual

6
QDisanaxialfandesignedtoensureairextractioninsmall/medium-sizedroomssuch
asbathrooms,toiletsandkitchens.
Suitableforairdischargedirectlytotheoutsideorinthepresenceofshortlinearduct
(lessthan1.5m).Wall,ceilingorwindowinstallation(fig.1).
•Material:highquality,impactandUV-resistantABScolourRAL9010.
•Designfrontcoverremovableforcleaningwithouttheuseoftools.
•Rearreinforcementringtopreventspigotdeformationduringinstallation.
•High efficiency aerodynamic fan with “winglet” blades to optimise quietness and
efficiency.
•Singlephaseinductionmotorwithintegralthermalprotection.
•Motormountedonhighqualitysleevebearings.
•BBversion(onrequest):motormountedonballbearingsthatguaranteealonger
productlifecycle(30,000h)andsuitableforcoldclimates.
•Thefanisdoubleinsulated:noearthconnectionisrequired.
•Suitableforcontinuousorintermittentoperation.
•IPX4degreeofprotection.
•Powersupply220Vto240V~50/60Hz.
order to ensure proper device operation.
•Iftheenvironmentinwhichtheproduct is installed also houses a fuel-operating
device(waterheater,methanestoveetc.,thatisnota“sealedchamber”type),it
isessentialtoensureadequateairintake,toensuregoodcombustionandproper
equipment operation.
•Installtheproductsothattheimpellerisnotaccessiblefromtheairoutletsideas
verifiedbycontactwiththeTestFinger(testprobe“B” ofthenormEN61032)in
compliancewiththecurrentsafetyregulations.
•Ceilinginstallation
In order to guarantee the IPX4 degree of protection against moisture in case of
ceilinginstallation,usetheappropriateceilingmountkit,whichisnotincluded.Use
onlytherearentryholeforsupplycables.Ifthereisapossibilityofcondensation
alongtheairdischargeduct,provideadrainagesystemtopreventcondensation
from discharging into the environment through the fan.
Attention:donotmounttheproductontheceilingwithoutthiskit.
•Windowinstallation
 Incaseofwindowinstallationitisnecessarytousetheappropriatewindowkit,
whichisnotincluded.
Attention:donotmounttheproductonthewindowwithoutthiskit.
INTRODUCTION
TECHNICAL SPECIFICATIONS
STANDARD
ThefanisoperatedusingaseparateON/OFFswitchorviaalightswitch(fig.13A).
PULL CORD
Thefanisoperatedusinganintegratedpullcordswitch(fig.13C).
WITH TIMER (over-run)
Thefanisprovidedwithatimercircuitwhichisadjustablefromaprox.1minuteto25
minutesviatrimmer(fig.14B).
VERSIONS
