2 – DIMENSIONS AND WEIGHTS
2.1 Dimensions (horizontal version unit)
The following table, referred to the figure, shows dimensions and weights of QRCE series (horizontal version) and its
accessories.
Horizontal configurations
A : supply air at right side looking at the electrical panel (like in the drawing above)
B : supply air at left side looking at the electrical panel
Model
500
1000
1500
2000
3000
4000
L
mm
1350
1470
1850
1850
2150
2150
W
mm
680
820
1030
1460
1460
1840
H
mm
330
370
455
455
590
590
W1
mm
760
900
1110
1540
1540
1920
X
mm
230
300
390
600
590
780
Y
mm
225
265
350
350
485
485
E
mm
52.5
52.5
52.5
52.5
52.5
52.5
F
mm
46
46
46
46
55
55
G
mm
128
130
158
170
170
170
D1
mm
1/2" M
D2
mm
3/4" M
3/4" M
3/4" M
3/4" M
1" M
1" M
L1
mm
350
400
400
400
502
502
L2
mm
340
380
460
460
580
580
Weight (basic units)
kg
85
105
175
230
290
360
Weight (CCS/CDX)
kg
28/28
31/31
35/35
42/42
52/52
58/58
Weight (PLM)
kg
21
23
26
30
39
44
QRCE
PLM
CCS
(CDX)
D2
D2
Fresh air
Supply air
Return air
Exhaust air
