APPENDIX F
F-2
35 (89)
49 (124)
57 (145)
47 (119)
30-1/8
16-3/4
23-1/4
68-1/2
77-1/8
72-1/2
14-3/8
19 (48)
22-1/4 (57)
15-1/2 (39)
29
3 (8)
6 (15) I.D.
FLUE CONN.
3/4 (2) DIA.
(ENCLOSURE)
c.g.
PRESSURE
RELIEF
4-150# FLG'D
4-150# FLG'D
SYS. WATER SUPPLY
SYS. WATER RETURN
AC SERVICE CONN.
3/4 CONDUIT
120VAC SINGLE PHASE
20 AMP W/GRD
c.g.
3-1/8
(184)
5-3/4 (15)
REMOTE ALARM & CONTROL
CONNECTION - 3/4 CONDUIT
1-1/4NPT GAS INLET
(77)
(174)
(59)
(43)
(196)
(37)
SHELL CAP
VALVE
COMB. AIR INTAKE
(OPTIONAL O.A.
INLET ADAPTER
1"NPT
DRAIN
VALVE
5/8" I.D
MALE HOSE
CONDENSATE
DRAIN
MODEL KC
STYLE
KC SERIES GAS FIRED BOILER
DIMENSIONAL DRAWING
AP-A-816
A
NOTES:
1) DRAIN VALVE AND RELIEF VALVE ARE INCLUDED SEPARATELY IN SHIPMENT
2) A 1/4" PER FOOT FLUE PITCH BACK TOWARDS THE HEATER MUST BE
MAINTAINED TO ALLOW THE FLOW OF ANY CONDENSATE FORMED IN THE
FLUE TO FLOW TO THE DRAIN
3) ALL DIMENSIONS SHOWN ARE IN INCHES (CENTIMETERS)
22 (56)
(FLOOR FLANGE)
(TYP)
(OUTLET)
(INLET)
GK 2-1-95
TYP.
4-PLCS
(
)
14-3/4 (37)
AERCO
INTERNATIONAL INC.
NORTHVALE, NEW JERSEY 07647
CHKD
APPD
13-9/16
(34.4)
TRAIN OPTION" ONLY
CONN. FOR "IRI GAS
3/4" NPT GAS VENT
AVAIL. - 6" OD)
ASME B & PV CODE SECTION IV STAMP H
HEAT EXCHANGER DESIGN STANDARDS
SHELL SIDE
PRESS. (PSIG)
150
MAX. WORKING
225
TEST PRESS.
(PSIG)TEMP. (°F)
25
MAXIMUM
REV.
