AERMEC 1802 - 19.6. Carpentry by 7160 mm (Two Circuits)

INSPY. 1003. 4138305_03
60
19.6. CARPENTRY BY 7160 (mm) electrical box two circuits
NS 3402 - 3602
°°(°/L°°00…PA…PK)
WARNING:
ALWAYS USE ALL THE
PROVIDED EYEBOLTS
FOR THE LIFTING OF
THE UNIT
1
73 5
82 4 6
POSITION OF VIBRATION DAMPERS
STRUT POSITION FOR LIFTING
NS
Heat recovery
Version
Hydronic kit
(1)
Weight and centre
of gravity
when empty
(kg)
Support 1 Support 2 Support 3 Support 4 Support 5 Support 6 Support 7 Support 8
Kit AVX
kgx y%%%%%%%%
3402 ° °/L 00 6770
3296 1197 11 14 7 10 17 20 9 11 509
3602 ° °/L 00 7280 3159 1205 12 15 10 12 15 18 8 10 507
3402 D °/L 00 6840 3296 1197 11 14 7 10 17 20 9 11 509
3602 D °/L 00 7360 3159 1205 12 15 10 12 15 18 8 10 507
3402 T °/L 00 6770 3336 1231 10.6 13.5 7.9 10 16.5 21 9 11.5 509
3602 T °/L 00 7980 3159 1247 11.4 14.9 10 13.1 13.7 17.9 8.2 10.8 507
(1) the weight of the pumps to be add-
ed to the version without hydronic kit
− PA 69 kg
− PB 138 kg
− PC 75 kg
− PD 150 kg
− PE 91 kg
− PF 182 kg
− PG 100 kg
− PH 200 kg
− PJ 108 kg
− PK 216 kg
Lato evaporatori
Lato compressori
Lato evaporatori
Lato compressori
Lato evaporatori
Lato compressori
0
x
y
YG
XG
1
2
3
5
7
4
6
8
9
11
13
15
10
12
14
16
17
19
21
23
18
20
22
24
