16
Aermec IDMKUJ. 0113.5356200_01
DMK
EN
The collection of condensate can be done in
two ways:
1. In the condensate collection bucket
which has to be periodically emptied.
2. Directly to a drain.
WARNING:
With either method the dehumidifier will
not operate if the condensate collection
bucket is not correctly fitted.
1. EMPTYING THE CONDENSATE
COLLECTION BUCKET
If the tube for direct drain is not con-
nected the condensate is collected in
the condensate collection bucket until
it is full (4.9 litres). When the conden-
sate collection bucket is full the indicator
BUCKER FULL will light up and the dehu-
midifier will stop automatically. See the
paragraph CLEANING THE CONDENSATE
COLLECTION BUCKET.
Do not remove the condensate collec-
tion bucket when the dehumidifier is
in operation or when it has just been
switched off.
condensate
water level
2. DIRECT DRAIN
The dehumidifier can be connected
directly to a drain with a rubber tube
of 14 mm internal diameter (not pro-
vided), thereby operating without the
need to empty the condensate collec-
tion bucket.
WARNING: DISCONNECT THE
PLUG BEFORE CONNECTING THE
DEHUMIDIFIER TO THE DRAIN.
To connect to the drain follow these
instructions:
1. Open the cover on the side of the
dehumidifier.
2. Remove the rubber plug.
3. Manually insert the rubber tube to
the drain outlet connection. Ensure
there are no leaks.
4. Periodically check the condensate
drain system is working correctly
WARNING: Ensure the condensate
drain tube remains below the outlet
level of the unit so that there is a slope
for the condensate to drain naturally.
WARNING: To revert to the normal
drain method stop the dehumidifier,
wait until the drain tube is completely
empty, otherwise the water will drain
without being collected in the conden-
sate collection bucket. Remember to
refit the rubber plug to the outlet tube.
17. CONDENSATE COLLECTION BUCKET
