AERMEC EXW 070 - Dimensions and Minimum Technical Space

Fig. 2
Fig. 3
9
DIMENSIONI E SPAZI TECNICI MINIMI – DIMENSIONS AND MINIMUM TECHNICAL SPACE (mm)
DIMENSIONS ET ESPACES TECHNIQUES MINIMUM – ABMESSUNGEN UND MINIMUM WANDABSTÄNDE (mm)
Mod. A B C
EXW - EXW H 278 815 198
=
=
Fig. 1
Peso netto - Net weight - Poids net - Nettogewicht (kg)
070 090 120
EXW 9910
EXW H 91010
Fig. 4
