27
IFCLTY 1112 - 4528511_04
Tw
[°C]
T [°C]
Ta
W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 3031 3031 3785 3785 4517 4517 5232 5232 5947 5947 6302 6302
17 4136 3152 4285 3967 4607 4607 5245 5245 5960 5960 6315 6315
19 6431 3179 6418 3954 6405 4720 6411 5497 6547 6294 6624 6624
21 8841 3940 8822 4715 8803 5481 8784 6246 8775 6623
23 11418 4677 11390 5449 11371 6221 11353 6601
5
15 2474 2474 3315 3315 4104 4104 4865 4865 5606 5606 5973 5973
17 2848 2539 3454 3454 4111 4111 4871 4871 5619 5619 5986 5986
19 5077 2625 5090 3402 5245 4220 5535 5073 5915 5915 6128 6128
21 7707 3479 7694 4252 7694 5022 7694 5791 7732 6190
23 10359 4251 10359 5030 10322 5790 10322 6177
7
15 1448 1448 2603 2603 3531 3531 4362 4362 5155 5155 5541 5541
17 1452 1452 2616 2616 3537 3537 4375 4375 5168 5168 5548 5548
19 2397 1566 3312 2641 4001 3624 4639 4572 5264 5264 5586 5586
21 5992 2813 6005 3589 6186 4414 6469 5271 6637 5699
23 9047 3744 9037 4514 9028 5281 9009 5656
13
3
15 2255 2255 3028 3028 3773 3773 4497 4497 5213 5213 5567 5567
17 2435 2358 3035 3035 3782 3782 4504 4504 5226 5226 5580 5580
19 4433 2368 4420 3129 4530 3928 4794 4750 5239 5239 5593 5593
21 6882 3155 6869 3924 6856 4683 6843 5442 6875 5835
23 9459 3902 9450 4674 9422 5434 9412 5813
5
15 1533 1533 2500 2500 3325 3325 4104 4104 4858 4858 5232 5232
17 1539 1539 2503 2503 3331 3331 4111 4111 4871 4871 5245 5245
19 2410 1575 3022 2530 3608 3459 4195 4195 4878 4878 5251 5251
21 5490 2624 5490 3392 5606 4188 5851 5025 5992 5442
23 8260 3450 8241 4213 8222 4971 8222 5353
7
15 731 731 1461 1461 2661 2661 3557 3557 4381 4381 4775 4775
17 731 731 1461 1461 2661 2661 3570 3570 4388 4388 4781 4781
19 754 736 1468 1468 2693 2693 3576 3576 4394 4394 4794 4794
21 2783 1638 3570 2644 4227 3599 4833 4532 5116 4983
23 6521 2823 6521 3585 6650 4390 6753 4803
15
3
15 1442 1442 2258 2258 3022 3022 3760 3760 4478 4478 4839 4839
17 1445 1445 2261 2261 3028 3028 3769 3769 4491 4491 4845 4845
19 2107 1461 2548 2337 3080 3080 3776 3776 4497 4497 4858 4858
21 4742 2348 4729 3101 4807 3886 5019 4698 5168 5105
23 7365 3124 7359 3886 7333 4638 7326 5014
5
15 585 585 1585 1585 2516 2516 3331 3331 4104 4104 4485 4485
17 587 587 1585 1585 2519 2519 3338 3338 4111 4111 4491 4491
19 590 590 1598 1598 2526 2526 3344 3344 4124 4124 4497 4497
21 2642 1590 3209 2513 3763 3424 4317 4315 4601 4601
23 5902 2607 5902 3364 5973 4145 6063 4552
7
15 116 116 731 731 1520 1520 2700 2700 3582 3582 3995 3995
17 116 116 731 731 1520 1520 2706 2706 3589 3589 4001 4001
19 116 116 731 731 1526 1526 2713 2713 3595 3595 4008 4008
21 758 723 1572 1572 2790 2790 3628 3628 4021 4021
23 3131 1676 3853 2641 4472 3572 4768 4030
COOLING CAPACITY - FCL102
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [w] = Total Cooling capacity
Ps [w] = Sensible Cooling capacity
Qv [m
3
/h] = Air flow rate
NB: the output values in bold type indicate the nominal value.
If sensible output values are above the total output, this means that
cooling is carried out without dehumidification.
If this occurs, take into consideration only the sensible output values.
The Cooling capacity of the table are at maximum speed (maximum
air flow). To determine the Cooling capacity based on the speed
(air flow), the values shown in the table must be multiplied by the
following factors (k):
FCL102
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4
1350 11
Speed V3
1010 0,78 0,77
Speed V2
830 0,66 0,65
Speed V1 (Minimum)
560 0,45 0,44
COOLING CAPACITY CORRECTION FACTORS
