6
Basin
Thermal exchange battery
.
Basin closing off the unit.
Made of injection co-moulded
polystyrene to avoid thermal
dispersion and the formation
of condensate, it conveys
conditioned air towards the
louvres and from the
condensate drip basin. The
air intake conveyor is
equipped with a protective
grille that impedes access to
the moving fan.
The coils used have copper
pipes and corrugated or
turbulent aluminium louvres.
They are designed to offer
the maximum heat exchange
surface. All batteries are
provided with air bleed pipes
and water drain valves,
located respectively on the
highest and lowest point of
the battery circulation.
