18
IFCLITY1106 - 5773010_01
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 1229 1229 1535 1535 1832 1832 2122 2122 2412 2412 2556 2556
17 1677 1382 1738 1738 1868 1868 2127 2127 2417 2417 2561 2561
19 2608 1394 2603 1734 2598 2070 2600 2410 2655 2655 2686 2686
21 3585 1728 3578 2067 3570 2403 3563 2738 3559 2904
23 4631 2051 4619 2389 4612 2728 4604 2894
5
15 1003 1003 1344 1344 1665 1665 1973 1973 2273 2273 2422 2422
17 1155 1113 1401 1401 1667 1667 1976 1976 2279 2279 2428 2428
19 2059 1151 2064 1492 2127 1850 2245 2224 2399 2399 2485 2485
21 3125 1525 3120 1864 3120 2202 3120 2539 3136 2714
23 4201 1864 4201 2206 4186 2539 4186 2708
7
15 587 587 1056 1056 1432 1432 1769 1769 2091 2091 2247 2247
17 589 589 1061 1061 1435 1435 1774 1774 2096 2096 2250 2250
19 972 687 1343 1158 1623 1589 1881 1881 2135 2135 2266 2266
21 2430 1233 2436 1573 2509 1935 2624 2311 2692 2499
23 3669 1641 3665 1979 3661 2316 3654 2480
13
3
15 915 915 1228 1228 1530 1530 1824 1824 2114 2114 2258 2258
17 988 988 1231 1231 1534 1534 1827 1827 2119 2119 2263 2263
19 1798 1038 1793 1372 1837 1722 1944 1944 2125 2125 2268 2268
21 2791 1383 2786 1720 2780 2053 2775 2386 2788 2558
23 3836 1711 3832 2049 3821 2382 3817 2549
5
15 622 622 1014 1014 1348 1348 1665 1665 1970 1970 2122 2122
17 624 624 1015 1015 1351 1351 1667 1667 1976 1976 2127 2127
19 977 691 1226 1109 1463 1463 1701 1701 1978 1978 2130 2130
21 2226 1151 2226 1487 2273 1836 2373 2203 2430 2386
23 3350 1513 3342 1847 3334 2179 3334 2347
7
15 297 297 593 593 1079 1079 1442 1442 1777 1777 1936 1936
17 297 297 593 593 1079 1079 1448 1448 1780 1780 1939 1939
19 306 306 595 595 1092 1092 1450 1450 1782 1782 1944 1944
21 1129 718 1448 1159 1714 1578 1960 1960 2075 2075
23 2645 1238 2645 1572 2697 1925 2739 2106
15
3
15 585 585 916 916 1226 1226 1525 1525 1816 1816 1962 1962
17 586 586 917 917 1228 1228 1529 1529 1821 1821 1965 1965
19 854 641 1033 1025 1249 1249 1531 1531 1824 1824 1970 1970
21 1923 1029 1918 1360 1949 1704 2036 2036 2096 2096
23 2987 1370 2984 1704 2974 2033 2971 2198
5
15 237 237 643 643 1020 1020 1351 1351 1665 1665 1819 1819
17 238 238 643 643 1022 1022 1354 1354 1667 1667 1821 1821
19 239 239 648 648 1024 1024 1356 1356 1672 1672 1824 1824
21 1071 697 1301 1102 1526 1501 1751 1751 1866 1866
23 2394 1143 2394 1475 2422 1817 2459 1996
7
15 47 47 297 297 616 616 1095 1095 1453 1453 1620 1620
17 47 47 297 297 616 616 1097 1097 1455 1455 1623 1623
19 47 47 297 297 619 619 1100 1100 1458 1458 1625 1625
21
308 308 637 637 1131 1131 1471 1471 1631 1631
23 1270 735 1563 1158 1814 1566 1934 1767
COOLING CAPACITY - FCLI 44
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
COOLING CAPACITY CORRECTION FACTORS
FCLI 44
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0.82 0.75
Speed V2 360 0.64 0.58
Speed V1 260 0.50 0.43
