IFCLITY1106 - 5773010_01
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 1677 1677 2095 2095 2499 2499 2895 2895 3291 3291 3487 3487
17 2288 1803 2371 2270 2549 2549 2902 2902 3298 3298 3494 3494
19 3558 1819 3551 2262 3544 2700 3548 3145 3622 3601 3665 3665
21 4892 2254 4881 2697 4871 3136 4861 3573 4856 3789
23 6318 2676 6303 3117 6292 3559 6282 3776
5
15 1369 1369 1834 1834 2271 2271 2692 2692 3102 3102 3305 3305
17 1576 1453 1911 1911 2275 2275 2695 2695 3109 3109 3312 3312
19 2810 1502 2817 1946 2902 2414 3063 2902 3273 3273 3391 3391
21 4264 1990 4257 2432 4257 2873 4257 3313 4279 3541
23 5732 2432 5732 2878 5711 3313 5711 3534
7
15 801 801 1440 1440 1954 1954 2414 2414 2852 2852 3066 3066
17 803 803 1447 1447 1957 1957 2421 2421 2859 2859 3070 3070
19 1326 896 1833 1511 2214 2073 2567 2567 2913 2913 3091 3091
21 3316 1609 3323 2053 3423 2525 3580 3016 3672 3261
23 5006 2142 5001 2582 4996 3021 4985 3236
13
3
15 1248 1248 1676 1676 2087 2087 2489 2489 2884 2884 3080 3080
17 1348 1348 1679 1679 2093 2093 2492 2492 2892 2892 3088 3088
19 2453 1355 2446 1790 2506 2247 2653 2653 2899 2899 3095 3095
21 3808 1805 3801 2245 3794 2679 3786 3113 3804 3338
23 5234 2232 5229 2674 5213 3109 5208 3325
5
15 848 848 1383 1383 1840 1840 2271 2271 2688 2688 2895 2895
17 852 852 1385 1385 1843 1843 2275 2275 2695 2695 2902 2902
19 1333 901 1672 1447 1997 1979 2321 2321 2699 2699 2906 2906
21 3038 1501 3038 1941 3102 2396 3237 2875 3316 3113
23 4570 1974 4560 2410 4550 2844 4550 3062
7
15 405 405 809 809 1472 1472 1968 1968 2424 2424 2642 2642
17 405 405 809 809 1472 1472 1975 1975 2428 2428 2645 2645
19 417 417 812 812 1490 1490 1979 1979 2432 2432 2653 2653
21 1540 937 1975 1512 2339 2059 2674 2593 2831 2831
23 3608 1615 3608 2051 3680 2512 3737 2748
15
3
15 798 798 1250 1250 1672 1672 2080 2080 2478 2478 2678 2678
17 800 800 1251 1251 1676 1676 2086 2086 2485 2485 2681 2681
19 1166 836 1410 1337 1704 1704 2089 2089 2489 2489 2688 2688
21 2624 1343 2617 1774 2660 2223 2777 2688 2859 2859
23 4075 1787 4072 2223 4057 2653 4054 2869
5
15 324 324 877 877 1392 1392 1843 1843 2271 2271 2481 2481
17 325 325 877 877 1394 1394 1847 1847 2275 2275 2485 2485
19 326 326 884 884 1398 1398 1850 1850 2282 2282 2489 2489
21 1462 910 1775 1438 2082 1959 2389 2389 2546 2546
23 3266 1492 3266 1924 3305 2371 3355 2604
7
15 64 64 405 405 841 841 1494 1494 1982 1982 2210 2210
17 64 64 405 405 841 841 1497 1497 1986 1986 2214 2214
19 64 64 405 405 844 844 1501 1501 1989 1989 2218 2218
21
420 414 870 870 1544 1544 2007 2007 2225 2225
23 1733 959 2132 1511 2474 2043 2638 2305
COOLING CAPACITY - FCLI 62
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
COOLING CAPACITY CORRECTION FACTORS
FCLI 62
Qv [m
3
/h] k (Pc) k (Ps)
Speed V4 880 1 1
Speed V3 660 0.79 0.74
Speed V2 500 0.64 0.60
Speed V1 380 0.53 0.49
To Next Page
