21
English
Minimum average water temperature
If the fan coil is working in continuous
cooling mode in an environment where
the relative humidity is high, condensate
might form on the air delivery and
on the outside of the device. This
condensate might be deposited on any
objects underneath and on the floor.
To avoid condensate on the external struc-
ture of the apparatus with the fan in
operation, the average temperature of
the water must not be lower than the lim-
its shown in the table below, that depend
on the thermo-hygrometric condition of
the air in the environment.
The limits mentioned above refer to opera-
tion while the fan is set
to its minimum speed level.
d,E/>dEKWZd/E'>/D/d^
WĞƌĨŽƌŵĂŶĐĞǀĂůƵĞƐƌĞĨĞƌƚŽƚŚĞĨŽůůŽǁŝŶŐĐŽŶĚŝƟŽŶƐ
- at the maximum motor speed;
- the total input power is determined by adding the input power
for the unit to the input power for the accessories connected and
declared in the corresponding manuals.
Water temperature
In order to prevent air stratification in the
room, and therefore to achieve improved
mixing, it is advisable not to supply the fan coil
with water at a temperature over 65°C.
The use of water at high temperatures
could cause squeaking due to the different
thermal expansions of the elements (plastics
and metals), this does not however cause
damage to the unit if the maximum operating
temperature is not exceeded.
D,/EWhZWK^
The fan coil is a room air treatment terminal unit for both winter and summer operation.
FCLI VERSION
Cassette-type fan coil with Inverter for installation in suspended ceilings; can be integrated in standard 600x600 and
840x840 panelling.
^Z/Wd/KEK&d,hE/d
AVAILABLE SIZES
The cassette-type fan coils of the FCLI range are available in:
for 2-pipe systems
FCLI 32 (600x600)
FCLI 42 (600x600)
FCLI 62 (600x600)
FCLI 82 (840x840)
FCLI 122 (840x840)
For 4-pipe systems
FCLI 34 (600x600)
FCLI 44 (600x600)
FCLI 64 (600x600)
FCLI 124 (840x840)
GLLI100 GLLI100N GLLI100EH ;ϲϬϬdžϲϬϬͿ '>>/ ϮϬ ;ϴϰϬdžϴϰϬͿ 'ƌŝůůĞ ƵŶŝƚ ǁŝƚŚ ƐƵĐƟŽŶ ĂŶĚ ĚĞůŝǀĞƌLJ ĮůƚĞƌ ǁŝƚŚ ŵĂŶƵĂůůLJ
adjustable fins; requires an external control panel with thermostat and ventilation speed control, with 0-10V
output.
'Z/>>hE/dΈK>/'dKZz^^KZzΉ
FCLI 32 34 42 44 62 64 82 122 124
Maximum recommended temperature 65°C
Maximum water inlet temperature 80°C
DĂdžŝŵƵŵŽƉĞƌĂƟŶŐƉƌĞƐƐƵƌĞ kPa 800 (8 bar)
DŝŶŝŵƵŵŽƉĞƌĂƟŶŐƉƌĞƐƐƵƌĞ kPa 100 (1 bar)
Room temperature limit R.T.
0°C
<Ta<40 °C
Room temperature limit R.H.
R.H.
< 85%
DŝŶŝŵƵŵĚĞůŝǀĞƌLJ;ŚĞĂƟŶŐͿ °C 100 50 100 50 150 50 250 350 50
DĂdžŝŵƵŵĚĞůŝǀĞƌLJ;ŚĞĂƟŶŐͿ °C 750 400 750 400 1050 400 1750 2450 400
Minimum delivery (cooling) °C 100 100 100 100 150 150 250 350 250
Maximum delivery (cooling) °C 750 750 750 750 1050 1050 1750 2450 1750
Maximum input current A
0.22 0.22 0.33 0.33 0.37 0.37 0.7
0.75
0.75
Power supply V / Hz
230V (
±10%) 50 Hz
MINIMUM AVERAGE WATER TEMPERATURE [°C]
Ambient air temperature with dry bulb
21 23 25 27 29 31
Ambient air temperature
with wet bulb
15333333
17333333
19333333
21654333
23-87655
