COIL PRESSURE DROPS (VL version without valve)
Pressure drops [kPa] - Heating with 50°C water
Water fl ow rate [l/h] FCLI32 FCLI42 FCLI62 FCLI82 FCLI122
100
1.07 0.73 0.67 0.34 0.17
200
3.71 2.55 2.33 1.20 0.60
300
7.71 5.29 4.84 2.49 1.24
400
12.93 8.87 8.12 4.18 2.07
500
19.33 13.26 12.13 6.24 3.10
600
26.84 18.41 16.84 8.67 4.30
700
35.42 24.30 22.23 11.44 5.68
800
45.04 30.90 28.27 14.54 7.22
900
55.68 38.19 34.95 17.98 8.93
1000
67.31 46.17 42.25 21.73 10.79
1100
79.90 54.81 50.15 25.80 12.81
1200
93.45 64.10 58.66 30.17 14.98
1300
107.93 74.04 67.75 34.85 17.30
1400
123.34 84.60 77.41 39.82 19.77
1500
139.64 95.79 87.65 45.09 22.39
1600
156.85 107.59 98.45 50.64 25.14
1700
174.93 120.00 109.80 56.48 28.04
1800
193.89 133.00 121.70 62.60 31.08
1900
213.70 146.59 134.13 69.00 34.26
2000
234.37 160.77 147.11 75.68 37.57
2100
255.89 175.53 160.61 82.62 41.02
2200
278.24 190.86 174.64 89.84 44.60
2300
301.42 206.76 189.19 97.32 48.32
2400
325.41 223.22 204.25 105.07 52.17
2500
350.23 240.24 219.82 113.08 56.15
Pressure drops [kPa] - Heating with 70°C water
Water fl ow rate [l/h] FCLI34 FCLI44 FCLI64 FCLI124
50
0.74 0.70 0.71 0.12
100
2.58 2.44 2.49 0.40
150
5.34 5.06 5.16 0.84
200
8.97 8.49 8.67 1.41
250
13.40 12.69 12.95 2.10
300
18.61 17.62 17.98 2.92
350
24.56 23.26 23.73 3.85
400
31.24 29.58 30.18 4.89
500
46.68 44.20 45.10 7.31
600
64.81 61.36 62.62 10.15
700
85.53 80.99 82.64 13.40
800
108.77 102.99 105.10 17.04
900
134.46 127.31 129.92 21.06
1000
162.53 153.90 157.05 25.46
1100
192.95 182.70 186.44 30.23
1200
225.67 213.68 218.05 35.35
1300
260.64 246.80 251.84 40.83
1400
297.84 282.01 287.78 46.65
1500
337.22 319.30 325.83 52.82
1600
378.76 358.64 365.97 59.33
1700
422.43 399.99 408.17 66.17
1800
468.21 443.33 452.40 73.34
1900
516.06 488.65 498.64 80.84
2000
565.98 535.91 546.87 88.66
