32
IFCLITY1106 - 5773010_01
COIL PRESSURE DROPS (VL version without valve)
Pressure drops [kPa] - Cooling with 7°C water
Water fl ow rate [l/h]
FCLI32 FCLI42 FCLI62 FCLI82 FCLI122 FCLI34 FCLI44 FCLI64 FCLI124
100
1.19 0.80 0.75 0.37 0.19 1.19 0.81 0.37 0.29
200
4.13 2.77 2.62 1.30 0.67 4.13 2.81 1.30 0.99
300
8.56 5.75 5.44 2.70 1.38 8.56 5.82 2.70 2.06
400
14.37 9.64 9.13 4.54 2.32 14.37 9.77 4.54 3.46
500
21.48 14.41 13.65 6.78 3.46 21.48 14.60 6.78 5.17
600
29.82 20.01 18.95 9.42 4.81 29.82 20.27 9.42 7.18
700
39.35 26.41 25.01 12.43 6.35 39.35 26.75 12.43 9.48
800
50.05 33.58 31.81 15.81 8.07 50.05 34.01 15.81 12.05
900
61.87 41.52 39.32 19.54 9.98 61.87 42.05 19.54 14.90
1000
74.78 50.19 47.53 23.62 12.06 74.78 50.83 23.62 18.01
1100
88.78 59.58 56.42 28.04 14.32 88.78 60.34 28.04 21.38
1200
103.83 69.68 65.99 32.80 16.74 103.83 70.57 32.80 25.01
1300
119.93 80.48 76.21 37.88 19.34 119.93 81.51 37.88 28.88
1400
137.04 91.96 87.09 43.29 22.10 137.04 93.14 43.29 33.01
1500
155.16 104.12 98.61 49.01 25.02 155.16 105.45 49.01 37.37
1600
174.27 116.95 110.75 55.05 28.10 174.27 118.44 55.05 41.97
1700
194.37 130.43 123.52 61.39 31.34 194.37 132.10 61.39 46.81
1800
215.43 144.57 136.91 68.05 34.74 215.43 146.42 68.05 51.89
1900
237.45 159.34 150.90 75.00 38.29 237.45 161.38 75.00 57.19
2000
260.42 174.75 165.50 82.26 41.99 260.42 176.99 82.26 62.72
2100
284.32 190.80 180.69 89.81 45.85 284.32 193.24 89.81 68.48
2200
309.15 207.46 196.47 97.65 49.85 309.15 210.11 97.65 74.46
2300
334.91 224.74 212.84 105.79 54.01 334.91 227.62 105.79 80.66
2400
361.57 242.64 229.78 114.21 58.30 361.57 245.74 114.21 87.08
2500
389.14 261.14 247.30 122.92 62.75 389.14 264.48 122.92 93.72
