AERMEC MEC-W - WATER CONNECTION DIAMETERS TABLE

56
DIAMETRO ATTACCHI IDRAULICI
WATER CONNECTIONS DIAMETERS
DIAMETRE RACCORDEMENTS HYDRAULIQUES
DURCHMESSER DER WASSERANSCHLÜSSE
TAB. 3
MOD.
Attacchi per acqua
Water connections
Raccordements eau
Anschlüsse für
Ingresso
Inlet
Entrée
Eintritt
Uscita
Outlet
Sortie
Austritt
Attacco scarico
condensa
Condensate con-
nection
Raccordement
condensats
Anschluß für
Kondensatablass
Ø
Ø
Ø
MEC 30 W 1/2” 1/2” 3/4”
MEC 50 W 3/4” 3/4” 3/4”
MEC 75 W 3/4” 3/4” 3/4”
MEC 100 W 1” 1” 3/4”
MEC 150 W 1
1/4”
1
1/4”
3/4”
