CARATTERISTICHE
•
FEATURES
Performances refer to following conditions:
❄ - temperature of processed water = 7 °C
- condenser entering water temperature = 30 °C.
-
∆ t = 5 °C
❊ - temperature of processed water = 50 °C
- evaporator entering water temperature = 10 °C.
-
∆ t = 5 °C
 - Sound pressure measured in a 85 m
3
semi-reverbera-
ting room and with a reverberating time Tr = 0,5sec.
M = male connection
Power supply = 400 V - 3+N - 50 Hz (±10%).
2027 H 3027 3027 H 4027 4027 H 6027 6027 H
53,5 67,2 67,2 88,5 88,5 112 112
15,9 22,2 22,2 26,4 26,4 37 37
28 39 39 47 47 65 65
3,36 3,03 3,03 3,35 3,35 3,03 3,03
9200 11560 11560 15220 15220 19260 19260
29 15 15 14 14 15 15
11940 15380 15380 19760 19760 25630 25630
54 60 49 12 12 19 19
63,8 – 83,3 – 97 – 131,5
21 – 27,4 – 29,3 – 39,3
37 – 48 – 52 – 68
3,04 – 3,04 – 3,31 – 3,35
10970 – 14330 – 16680 – 22620
42 – 42 – 8 – 15
7360 – 9610 – 11640 – 15860
21 – 11 – 9 – 10
2 x 3 2 x 3,85 2 x 3,5 2 x 6,8 2 x 6,8 2 x 6,5 2 x 6,5
Scroll
Alternativo Alternativo Alternativo Alternativo Alternativo Alternativo
Reciprocating Reciprocating Reciprocating Reciprocating Reciprocating Reciprocating
65 61,5 61,5 63,5 63,5 65 65
piastre • plate piastre • plate piastre • plate piastre • plate piastre • plate piastre • plate piastre • plate
2 x 2,44 1 x 8,5 1 x 8,5 1 x 12,5 1 x 12,5 1 x 14 1 x 14
1”/M 2”/M 2”/M 2”/M 2”/M 2”/M 2”/M
piastre • plate piastre • plate piastre • plate piastre • plate piastre • plate piastre • plate piastre • plate
2 x 2,44 2 x 2,63 2 x 3,2 2 x 7,75 2 x 7,75 2 x 7,75 2 x 7,75
1”/M 1”/M 1”/M 2”/M 2”/M 2”/M 2”/M
38 54 54 65 65 93 93
118 150 150 173 173 247 247
1000 1000 1000 1000 1000 1000 1000
800 1100 1100 1100 1100 1100 1100
700 750 750 750 750 750 750
307 336 336 486 486 500 500
