38
IREPPY - 1404 - 4238051_01
VMF-E5B
VMF-E5N
WARNING: the VMF-E5 allows the control of each master. The slave units
connected to each master are not individually controlled from the VMF-E5 panel
but follow the settings of the master they are connected to.
VMF E5
Wall recess mounted supervisor control
panel
Available in two colours:
• VMF-E5B white
• VMF-E5N black.
Back-lit graphic LCD display with capacitive
keypad.
allows the central-
ised command/control of a complete
hydronic system consisting of:
• Fan coil units: up to 64 fan coil zones
comprising 1 master + maximum 5 slaves.
• Chiller/heat pump unit equipped with
controls Modu_Control, GR3 and pCO2
/ PCO³ (required accessory RS 485 inter-
face respectively MODU-485A, AER485,
AER485P2 / AER485P1).
• Circulators: maximum of 12 configurable
zone circulators.
• Boiler: boiler enable for hot water pro-
duction.
• Heat recovery units: up to 3 outputs for
heat recovery units programmed accord-
the air quality obtained with the VMF-
VOC accessory.
• Domestic hot water module: complete
management of the production of domes-
tic hot water through the control of:
- Diverting valve/circulator
- Immersion heater
- Storage tank temperature sensor
- Anti-legionella cycle
The main characteristic consists in the pos-
sibility of controlling the system through
dedicated algorithms for reaching envi-
ronmental comfort with a view on energy
savings.
For complete information on the func-
tionality refer to the accessory manual.
Schemi collegamento RePuro- VMF E5 - VMF CRP - VMF VOC con indicate la pologia dei cavi di collegamento
VMF VOC
Air quality sensor accessory (see the item on
the description of the VMF-E5B)
