Dropped Ceiling Track Mount
You can mount the AP250 in either a square or diagonal position on a standard 15/16"-wide
track (2.38 cm) in a dropped ceiling. A diagonal mount requires the diagonal mount
bracket that ships with the device. This section describes how to do both installations.
Square Dropped Ceiling Track Mount
Slip the mount tabs over the edges of the ceiling track as shown in the illustration, then
rotate the device slightly until the mount clips click into place over the track edges.
Pag
e 9 of 15
Aerohive AP250
You can also mount these devices to non-standard or recessed dropped ceiling
tracks using brackets designed for 9/16" (1.34 cm) tracks. These brackets can be
ordered from Aerohive (AH- ACC-BKT-80211AC-KIT).
