Aerospace Logic FL20 Series User Manual

FL20X Product Specifications
Document # S200-FL20X-006
Rev 1.3 02/28/2017
Page 1 of 1
Aerospace Logic Inc.
Tel. 416-628-0725
www.aerospacelogic.com
Certification / Compliance
TSO C55a
Environmental DO-160F
A1CAASXXXXXXZBXXBBBCSBA1C11XXAX
Software DO-178B
DC Power Source Input voltage 6 to 36 VDC
Power consumption 100mA
Load dump tolerance +60V
Direct spike tolerance +/- 60V
Cable spike tolerance > +/- 1KV
Operating Temperature Constant operating -15ºC to +55ºC
Short term operating (1hr) -40ºC to +70ºC
Storage -55ºC to +85ºC
Signal Input Sender resistance 0.25 Ώ to 300 Ώ
Sender Orientation Installer selectable. Resistance proportional or
Inversely proportional to fuel quantity
Display Fuel Quantity US Gallons or Litres
Accuracy Fuel Quantity AS405C +/- 1 USG
Range 0 to 120 USG (defined by fuel sender/tank size)
Display Sunlight readable LCD
80/80/80/80 Degree viewing angle
Annunciator Output 100mA sink with reverse EMF protection
Interface Connector DB-25
Software Functionality
Primary Fuel level in all tanks
Trend Graph Graphic display of level vs time
Dimensions 2.45” X 2.45” X 0.9”
Weight (excluding harness) 4.05 oz
Finish Black anodized 6061 aluminum
