AETINA CONFIDENTIAL
UM-M3N1060-MN-v05
Package size: 37.5 mm x 37.5 mm, 2152 ball flip-chip, plastic ball grid array
(FCPBGA)
1.1.2 Board
GeForce GTX 1060
12-layer printed circuit board (PCB)
16-lanes PCI Express 3.0 capable (x16/x8)
MXM3.1 Type B form factor
Physical dimensions: 105mm x 82mm (single width)
Board power : 78 W
High-Bandwidth Digital Content Protection (HDCP) support
GeForce GTX 1070
12-layer printed circuit board (PCB)
16-lanes PCI Express 3.0 capable (x16/x8)
MXM3.1 form factor
Physical dimensions: 113mm x 82mm (single width)
Board power : 115 W
High-Bandwidth Digital Content Protection (HDCP) support
1.1.3 Memory Configuration
GeForce GTX 1060
Memory clock: 4004 MHz (8 Gbps)
Interface: 192-bit
Local frame buffer: 6 GB (6pieces 256M x 32 GDDR5, FBGA-170 package)
GeForce GTX 1070
Memory clock: 4004 MHz (8 Gbps)
Interface: 256-bit
Local frame buffer: 8 GB (6pieces 256M x 32 GDDR5, FBGA-170 package)
1.1.4 Support
NVIDIA CUDA Technology (Compute capability 6.1)
NVIDIA Optimus Technology
NVIDIA Ansel
NVIDIA GPU Boost 3.0
Microsoft DirectX 12
Vulkan
