AETINA CONFIDENTIAL
UM-M3N1060-MN-v05
1.2 Configuration
Table 1.1 lists the SKU configuration currently available for the GeForce GTX
1060/1070 MXM graphics module.
Table 1.1: Board configuration
Specification
M3N1060-MN Description
M3N1070-NN Description
Chip
GeForce GTX 1060
GeForce GTX 1070
Core clock
1404MHz (Boost: 1670MHz)
1442MHz (Boost: 1645MHz)
Memory clock
4004MHz (8.0 Gbps)
4004MHz (8.0 Gbps)
Frame buffer
6 GB GDDR5
8 GB GDDR5
Memory interface
192-bit
256-bit
Memory type
256M x 32 GDDR5 FBGA-170
package
256M x 32 GDDR5 FBGA-170
package
Memory AVL
Samsung K4G80325FB-HC25
Samsung K4G80325FB-HC25
Maximum board power
78 W
115 W
Connectors
MXM 3.0 Connector
Interoperability
MXM 3.0 Connector
Interoperability
HDCP support
Yes
Yes
Supplementary Power
Connector
N/A
4-pins (PWR_SRC)
Operating Temperature
Standard: 0°C to +55°C
Extreme temperature: Optional
Standard: 0°C to +55°C
Storage Temperature
-40°C to 125°C
-40°C to 125°C
Operating Humidity
10~90%, No Condensation.
10~90%, No Condensation.
