Page 8
NOTE: (These procedures should be done with the inlet tubes installed on the engine. It is shown off the
vehicle for better illustration.)
Step 13: Locate the o.e. plastic tube feeding the driver’s side turbo inlet.
Refer to Figure E for Step 13. ( For V6-3.5L (tt) only, not necessary on V6-2.7L (tt) )
Figure E
INSTALL
Vent insert installation:
To Next Page
