54
A
H
I
B
CD
A
F
G
E
MODEL INFORMATION
A) ADJUSTABLE LEVERS: allow adjustment to the height of both saddle post & handlebar
NOTE: To reposition the lever, pull lever outward and turn.
B) HEAVY FLYWHEEL: high-inertia flywheel creates a smooth feel
C) TRANSPORTATION WHEEL: allows for easy movement of the machine
D) BELT DRIVE: simulates the feel of road riding
E) CRANK: initiates movement to the flywheel
F) SADDLE POST: allows vertical adjustment to customize height for any user
G) SADDLE SLIDER: allows fore/aft adjustment to customize for any user
H) SADDLE: extra padding to provide a comfortable ride
I) TENSION CONTROL & EMERGENCY BRAKE LEVER: friction brake with micro-
adjustable knob and push-down emergency stop
NOTE: In case of emergency, press the emergency brake lever down to bring the
flywheel to an abrupt stop.
