7.3AU ASSEMBLY STEP 5
7.3AU
* NOTE: There is no hardware for this step.
A Attach the RIGHT PEDAL (17) to the RIGHT
CRANK ARM (18), tightening it CLOCKWISE with
the provided 13mm/15mm flat wrench.
B Attach the LEFT PEDAL onto the LEFT CRANK
ARM, tightening it COUNTER-CLOCKWISE with
the provided 13mm/15mm flat wrench. (NOTE: The
left crank arm is reversed threaded so it is very
important that it is tightened counter-clockwise.
Tightening it the opposite way can damage the
pedal or the crank arm or both.)
C Connect the CONSOLE CABLES (12) and
carefully tuck them into the CONSOLE MAST (11).
D Attach the CONSOLE (19) to the CONSOLE
MAST (11) using the 4 PRE-ATTACHED SCREWS
(20) (The screws will have to be removed from the
console first).
E Plug in POWER ADAPTER (21) as shown.
To Next Page
