ASSEMBLY COMPLETE!
Before the first use, lubricate the treadmill deck by
following the instructions in the MAINTENANCE
section in the TREADMILL GUIDE.
ASSEMBLY STEP 6
A Fold the deck into the upright position until
the FOOT LATCH (11) engages.
B Open HARDWARE FOR STEP 6.
C Attach BASE FRAME COVER (10) to
CONSOLE MAST (2) using 1 SCREW (H)
from the side.
D Attach BASE FRAME COVER (10) to BASE
FRAME (1) using 3 SCREWS (G) from
above.
E Repeat on other side.
F While holding the deck with both hands,
press the FOOT LATCH (11) with your foot to
lower the deck to the ground.
HARDWARE FOR STEP 6
PART TYPE QTY
G SCREW 6
H SCREW 2
