________________________________________________________ 17
4.3 Removal of Batteries
Batteries can be easily removed from your
SUPERLIGHT as follows -
a. Remove Seat and Rear Basket (see
instructions in paragraph 4.2 above).
b. Open Batteries Cover - (See Fig. 20).
1) Pull back Plastic Clip
2) Push the cover backward than up a little from
the rear slots in the power unit cover and than
forward out .
c. Disconnect cables from batteries: unplug
Battery Plugs.
d. Remove each battery by pulling it with it's handle .
(See Figure 21).
Figure 20 Figure 21
WARNING !!
Failure to follow above instructions could cause
pinching of your hand or fingers if battery slides down
and causes hand to come in contact with other parts.
