________________________________________________________ 4
CHAPTER 1 - DELIVERY and UNPACKING
The SUPERLIGHT Scooter is delivered to you
packed in one Cardboard Box. .
Note: The box weight 60kg (132 lb.) - do NOT attempt to
lift it with out assistance.
1.1 Unpack as follows (See Fig. 1)
a. Place boxes on floor with side up as marked by
the arrows on the side of the box.
b. Cut the Plastic Bands.
c. Remove the cardboard Top Cover.
d. Remove all parts from the boxes (and lay on the floor)
e. Identifying the SUPERLIGHT Components (See Fig. 1)
(1) Batteries Cover (2) Frame
(3) Seat (4) Batteries (left & right)
(5) Charger (6) Seat Adapter
(7) Tiller (8) Rear Basket
(9) Power Unit
Figure 1
