________________________________________________________ 7
d. Connect the Electric Plug to the Socket in the
Tiller (See Figure 6).
figure 6
2.3 Installation of Batteries (See Fig. 7)
Note: Installation of L.H Battery is identical to R.H.
Battery. L.H. Battery is shown.
a. Place battery in its location on the frame.
b. Connect Battery Plugs to battery.
Figure 7 – Small Battery Figure 8 – Large Battery
