Afore AF2500W-HB - 1 Technical Specication

01 02
Power
Module
Model
Number
of
power
modules
Number
of battery
Modules
Battery
System
Capacity
Battery Cell
Technology
Battery
System
Voltage
Operating
Voltage Range
Dimension (W*D*H) Net Weight
AF2500
W-HB
1
3 7.68kWh
Li-iron(LFP)
153.6V 134.4~168.48V
600*210*870(mm)
23.62*8.27*34.25(inch)
103.5kg
(228.18 lb)
4 10.24kWh 204.8V 179.2~224.64V
600*210*1030(mm)
23.62*8.27*40.55(inch)
130kg
(286.60 lb)
5 12.8kWh 256V 224~280.8V
600*2
10*1190(mm)
23.62*8.27*46.85(inch)
156.5kg
(345.02 lb)
6 15.36kWh 307.2V
268.8~336.96V
600*210*1350(mm)
23.62*8.27*53.15 (inch)
183kg
(403.45 lb)
7 17.92kWh 358.4V 313.6~393.12V
600*210*1510(mm)
23.62*8.27*59.45 (inch)
209.5kg
(461.87 lb)
8 20.48kWh 409.6V 358.4~449.28V
600*210*1670(mm)
23.62*8.27*65.75(inch)
236kg
(520.29 lb)
9 23.04kWh 460.8V 403.2~505.44V
600*210*1830(mm)
23.62*8.27*72.05(inch)
262.5kg
(578.71 lb)
10 25.6kWh 512V 448~561.6V
600*210*1990(mm)
23.62*8.27*78.35 (inch)
289kg
(637.14 lb)
2. Technical Specication
Scalability Installation
Depth of
Discharge
Battery
System
Charge
Current
(recommendl)
Battery
System
Charge
Current
(Max)
Battery
System
Discharge
Current
(recommend)
Battery
System
Discharge
Current
(Max)
Display Certficates
Max. Up to
10 systems
in series
operation
Floor stand 90% 25A 50A 25A 50A
The
information
of theBattery,
such as
SOC,
battery
status
Communic
ation Port
Protection
Class
Charging
temperatur
e
Discharge
temperature
Humidity
Max.
operating
altitude
Warranty Cooling
RS485,
CAN
IP65
0°C~55°C
(32°F-131°F)
-20°C~60°C
(-4°F-140°F)
5%-95%
2,000mm
(6,562ft.)
10 years
Natural
convection
Each Single
Battery
Module
Specification
Battery
Cell
Capacity
Configuration
Power module
dimensions
(W*D*H)
Battery Module
dimensions
(W*D*H)
Lampstand
Module
dimensions
(W*D*H)
Battery Module
Dimensions
(W*D*H)
50Ah 1P16S
600*210*250 (mm)
/ 23.62*8.27*9.84
(inch)
600*210*160 (mm)
/ 23.62*8.27*6.30
(inch)
600*210*90 (mm)
/ 23.62*8.27*3.54
(inch)
600*210*50 (mm)
/ 23.62*8.27*1.96
(inch)
Battery
Module
Capacity
Batte
ry
Module
Voltage
Power Module
Weight
Battery Module
Weight
Lampstand
Module Weight
Top cap Module
Weight
2.56kWh 51.2V 14kg (30.86lb) 27kg (59.52) 5kg (11.02Ib) 2.5kg (5.51Ib)
IEC62619 /
IEC61000 /
UN38.8 /
MSDS
