DMX BETRIEB
4 DMX Kanalbetrieb :
Kanal Wert Funktion
Beschreibung
CH1 0~255 Roter Dimmer Rot
CH2 0~255 Grüner Dimmer Grün
CH3 0~255 Blauer Dimmer Blau
CH4
0~9 Unbelegt
10~249 Stroboskop Stroboskop (von langsam auf schnell)
250~255 Unbelegt
BARCOB2: 10 DMX Kanalbetrieb:
Kanal Wert Funktion Beschreibung
CH1 0~255 Master dimmer Dimmer
CH2
0~9 No function
10~249 Strobe Strobe（From slow to fast）
250~255 No function
CH3 0~255 Red dimmer lens 1 Red
CH4 0~255 Green dimmer lens 1 Green
CH5 0~255 Blue dimmer lens 1 Blue
CH6 0~255 Red dimmer lens 2 Red
CH7 0~255 Green dimmer lens 2 Green
CH8 0~255 Blue dimmer lens 2 Blue
CH9
0~9 No function
10~119 Operating mode Auto program
120~255 Sound program
CH10 0~255 Auto program speed Speed for auto program（From slow to fast）
BARCOB4: 16 DMX Kanalbetrieb
Kanal Wert Funktion Beschreibung
CH1 0~255 Master dimmer Dimmer
CH2
0~9 No function
10~249 Strobe Strobe（From slow to fast）
250~255 No function
CH3 0~255 Red dimmer lens 1 Red
CH4 0~255 Green dimmer lens 1 Green
CH5 0~255 Blue dimmer lens 1 Blue
CH6 0~255 Red dimmer lens 2 Red
CH7 0~255 Green dimmer lens 2 Green
CH8 0~255 Blue dimmer lens 2 Blue
CH9 0~255 Red dimmer lens 3 Red
CH10 0~255 Green dimmer lens 3 Green
© Copyright LOTRONIC 2015 BARCOB2 / BARCOB4 Page 17
