AGA marvel ML15CL - Page 13

13
PRODUCT DIMENSIONS
PRODUCT DATA
MODEL
ELECTRICAL
REQUIREMENTS #
PRODUCT
WEIGHT
ML15C*S 115V/60Hz/15A
105 lbs
(47.7 kg)
ML15C*P 115V/60Hz/15A
105 lbs
(47.7 kg)
ML15C*G 115V/60Hz/15A
105 lbs
(47.7 kg)
* To install ML15C*P model with the door face ush with the
adjacent cabinet doors, custom decorative panel thickness
cannot exceed
3
⁄4" (19 mm).
** Minimum rough-in opening required is to be larger than
the adjusted height of the cabinet.
# A grounded 15 amp dedicated circuit is required. Follow
all local building codes when installing electrical and appli-
ance.
"F"
"D"
"E"
"H"
"J"
"G"
CL
Water
inlet
4
7
⁄8"
(12.4 cm)
1
1
⁄4"
(3.2 cm)
CL Gravity
drain
Figure 19
(S) solid
door shown
21
1
⁄2"
(54.6cm)
6
15
⁄16"
(17.6 cm)
