AGA ASXS21 - Kick plate; Removing the Kick Plate

36
Step. 1 Step. 4
Step. 5
Step. 6
Step. 3
With both hands grab the kick plate and
gently pull it towards you.
To avoid damage to the paintwork use masking tape to
cover left, middle and bottom. See step 2.
Starting on the right-hand side, use a
screwdriver to gently remove from the
white bracket.
Gently release from the middle bracket
Then again gently release from the left bracket.
Kick plate Masking tape
Masking tape Masking tapeMasking tape
Kick plate Masking tape
Step. 2
9. Kick plate
Removing the kick plate
