Fig. 32
Throttle pedal function deactivated
Appears for about 2 seconds when throttle pedal mode is switched off.
Fig. 33
Throttle pedal function active
Appears when the joystick is moved in the current direction of travel in throttle pedal mode. At
the same time a warning beep sounds.
Fig. 34
Steering column switch actuated
Steering column switch already actuated on tractor start-up.
Fig. 35
Steering axle active
Steering axle activated (information only)
3. Faults and remedy
Maintenance 91
530.020.020.011 Rev.A
