There are three ways for Alignment.
- Head Alignment
- Head Base Alignment
- Lamp House Alignment
Head Alignment
1) Control right & left slope of print head
2) Control up & down alignment of print head
3) Use two adjusting bolts and two fixing bolts.
There are M3 bolt and fix bolt
on both front side and back side.
Alignment
Alignment
