Agilent Technologies 34980A Service Guide

Troubleshooting and Diagnostics 4
34980A Service Guide 101
For the 34924A, relay part numbers are given on page 129 and the component locator is
shown on page 141. The table below shows the relationship of channel numbers to relay
numbers.
Bank 1 Bank 2
Channel Relay Channel Relay
001 K401 036 K501
002 K403 037 K503
003 K404 038 K504
004 K408 039 K508
005 K408 040 K508
006 K402 041 K502
007 K403 042 K503
008 K404 043 K504
009 K409 044 K509
010 K407 045 K507
011 K401 046 K501
012 K404 047 K505
013 K404 048 K504
014 K408 049 K508
015 K408 050 K508
016 K402 051 K502
017 K403 052 K503
018 K404 053 K505
019 K409 054 K509
020 K407 055 K507
021 K401 056 K501
022 K403 057 K503
023 K404 058 K504
024 K409 059 K509
025 K407 060 K507
026 K402 061 K502
027 K404 062 K505
028 K406 063 K506
028 K407 064 K507
030 K409 065 K509
031 K402 066 K502
032 K401 067 K501
033 K404 068 K505
034 K406 069 K506
035 K406 070 K506
Backplane Backplane
911 K611 921 K621
912 K612 922 K622
913 K613 923 K623
914 K614 924 K624
