132 34980A Service Guide
6 Replaceable Parts
34933A Replaceable Parts
A component locator is shown on page 146.
34937A Replaceable Parts
A component locator is shown on page 147.
34938A Replaceable Parts
A component locator is shown on page 148.
Component Locator Agilent P/N Description Vendor Vendor P/N
K501, K502, K503, K504,
K505, K506, K507, K508,
K601, K602, K603, K604,
K605, K606, K607, K608
0490-2746 RLY-DRY-RD-1A-8 PC
BUNDLE 0.5A 12V 300V
Coto 9000-0311
K921, K922, K923, K924 0490-1954 RELAY 2C 12VDC-COIL
2A 250VAC
Omron G6S-2-DC12
Component Locator Agilent P/N Description Vendor Vendor P/N
K601, K602, K603, K604,
K605, K606, K607, K608,
K609, K610, K611, K612,
K613, K614, K615, K616,
K617, K618, K619, K620,
K621, K622, K623, K624,
K625, K626, K627, K628
0490-1896 RELAY 2C 3VDC-COIL
2A 30VDC
Omron G6SU-2-DC3
K629, K630, K631, K632 0490-2731 RELAY 1A 9VDC-COIL
5A 30VDC THRU HOLE
Matsushita
DSP1A-L2-D
C9V-F
Component Locator Agilent P/N Description Vendor Vendor
P/N
K501, K502, K503, K504,
K505, K506, K507, K508,
K509, K510, K511, K512,
K513, K514, K515, K516,
K517, K518, K519, K520
0490-2731 RELAY 1A 9VDC-COIL
5A 30VDC THRU HOLE
Matsushita
DSP1A-L2-
DC9V-F
