Agilent Technologies 34980A Service Guide

Troubleshooting and Diagnostics 4
34980A Service Guide 105
For the 34931A, relay part numbers are given on page 130 and the component locator is
shown on page 144. The table below shows the relationship of channel numbers to relay
numbers.
Matrix 1 Matrix 2
Channel Relay Channel Relay
101 K7101 501 K8501
102 K7102 502 K8502
103 K7103 503 K8503
104 K7104 504 K8504
105 K7105 505 K8505
106 K7106 506 K8506
107 K7107 507 K8507
108 K7108 508 K8508
201 K7201 601 K8601
202 K7202 602 K8602
203 K7203 603 K8603
204 K7204 604 K8604
205 K7205 605 K8605
206 K7206 606 K8606
207 K7207 607 K8607
208 K7208 608 K8608
301 K7301 701 K8701
302 K7302 702 K8702
303 K7303 703 K8703
304 K7304 704 K8704
305 K7305 705 K8705
306 K7306 706 K8706
307 K7307 707 K8707
308 K7308 708 K8708
401 K7401 801 K8801
402 K7402 802 K8802
403 K7403 803 K8803
404 K7404 804 K8804
405 K7405 805 K8805
406 K7406 806 K8806
407 K7407 807 K8807
408 K7408 808 K8808
Backplane
921 K921
922 K922
923 K923
924 K924
