Agilent Technologies 34980A Service Guide

Troubleshooting and Diagnostics 4
34980A Service Guide 107
For the 34932A, relay part numbers are given on page 131 and the component locator is
shown on page 145. The table below and on the next page shows the relationship of
channel numbers to relay numbers.
Matrix 1 Matrix 2
Channel Relay Channel Relay
101 K7101 501 K8501
102 K7102 502 K8502
103 K7103 503 K8503
104 K7104 504 K8504
105 K7105 505 K8505
106 K7106 506 K8506
107 K7107 507 K8507
108 K7108 508 K8508
109 K7109 509 K8509
110 K7110 510 K8510
111 K7111 511 K8511
112 K7112 512 K8512
113 K7113 513 K8513
114 K7114 514 K8514
115 K7115 515 K8515
116 K7116 516 K8516
201 K7201 601 K8601
202 K7202 602 K8602
203 K7203 603 K8603
204 K7204 604 K8604
205 K7205 605 K8605
206 K7206 606 K8606
207 K7207 607 K8607
208 K7208 608 K8608
209 K7209 609 K8609
210 K7210 610 K8610
211 K7211 611 K8611
212 K7212 612 K8612
213 K7213 613 K8613
214 K7214 614 K8614
215 K7215 615 K8615
216 K7216 616 K8616
