Agilent Technologies 34980A - Introduction to the 34980 A

34980A Service Guide x
Module
• Open all relays
• Clear all measurement functions
• Clear channel labels
• Configure external trigger and clock (34951A)
• Set trace or level mode (34951A)
• Set waveform parameters (34951A)
View
• View errors and alarms
Advanced
Available at a later firmware release
Alarm
• Select one of four alarms to report alarm conditions on the displayed channel
• Configure a high limit, a low limit, or both for the displayed channel
• Select the slope (rising or falling edge) for the four alarm output lines
