34980A Service Guide xii

Agilent 34980A Dimensions (shown with Reverse Rack Mount brackets installed)

367.7 mm (14.48 in)

101.9 mm (4.01 in)

or

70.4 mm (2.78 in)

425.6 mm (16.76 in)
