Agilent Technologies 34980A Service Guide

16 34980A Service Guide
2 Specifications
Matrix Modules Specifications and Characteristics (continued)
[1]
50 source, 50 load, differential measurements verified (Sdd21)
[2]
With in-rush resistors bypassed.
[3]
With 100  input protection resistors.
34931A 34932A 34933A 34934A
AC characteristics
Bandwidth at terminal block
[1]
30 MHz 30 MHz 30 MHz
[2]
/4 MHz
[3]
2 MHz 1-wire
35 MHz 2-wire
15 MHz 1-wire
Crosstalk at terminal block (ch-ch)
[1]
300 kHz
1 MHz
20 MHz

–65 dB
–55 dB
–30 dB

–65 dB
–55 dB
–30 dB

–65 dB
–55 dB
–40 dB

–65 dB
–55 dB
–33 dB
Capacitance at terminal block
HI-LO
LO - earth

50 pF
80 pF

50 pF
80 pF

80 pF
75 pF

45 pF
250 pF

General characteristics
Relay life, typical
No load
10 V, 100 ma
Rated load

100 M
10 M 
100 k

100 M
10 M 
100 k

1000 M
10 M 
10 k


1000 M
operations
Open/close time 4 ms/4 ms 4 ms/4 ms 0.5 ms/0.5 ms 0.35 ms/0.10 ms
Analog bus backplane connection Bank 2 Bank 2 Bank 2 No
