Specifications 2
34980A Service Guide 37
System Specifications and Characteristics (continued)
[1]
Storage at temperatures above 40°C will decrease battery life.
[2]
Load IO Libraries Version M for Windows NT support or version 14.0 for Windows 98 SE support.
General specifications
Power supply Universal 100 V to 240 V ±10%
Power line frequency 50 – 60 Hz ±10% automatically sensed
Power consumption 150 VA
Operating environment Full accuracy for 0°C to 55°C
Full accuracy to 80% R.H. at 40°C
IEC 60664-1 pollution degree 1
Storage environment
–40°C to 70°C
[1]
Mainframe dimensions 133H x 426W x 341D mm (5.25” x 16.8” x 14”)
Full rack, 3 units high
Mainframe weight 8.8 kg (19.6 lbs)
Module dimensions 280 x 170 x 27 mm (11” x 6.7” x 1”)
Safety Conforms to CSA, UL/IEC/EN 61010-1
EMC Conforms to IEC/EN 61326-1, CISPR 11
Warranty 1 year
Software
Agilent IO Libraries Suite 14.0 or greater (E2094N) connectivity software included
Minimum system requirements (IO libraries and drivers)
PC hardware Intel Pentium 100 MHz, 64 Mbyte RAM,
210 Mbyte disk space
Display 800 x 600, 256 colors, CD-Rom drive
Operating system
[2]
Windows®98 SE/NT/2000/XP
Computer interfaces Standard LAN 10BaseT/100BaseTx
Standard USB 2.0
IEEE 488.2 GPIB
Software driver support for programming languages
Software drivers IVI-C and IVI COM for Windows NT/2000/XP
LabVIEW
Compatible with:
Agilent VEE Pro, Agilent T&M Toolkit (requires Visual Studio.NET)
National Instruments Test Stand, Measurement Studio, LabWindows/CVI, LabVIEW, Switch
Executive
Microsoft Visual Studio.NET, C/C++, Visual Basic 6
