Agilent Technologies 54622A Service Guide

1-9
General Information
Acquisition: Analog Channels
Performance Characteristics
* Denotes Warranted Specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and
±10 °C from firmware calibration temperature.
Acquisition: Analog Channels
Max Sample rate 200 MSa/s
Max Memory Depth 4 MB interleaved, 2 MB each channel
Vertical Resolution 8 bits
Peak Detection 5 ns
Averages selectable from 2, 4, 8, 16, 32, 64 ...to 16383
High Resolution Mode 12 bits of resolution when
≥500 us/div, average mode with average = 1
Filter: Sinx/x interpolation (single shot BW = sample rate/4 or bandwidth of scope, whichever
is less) with vectors on.
Acquisition: Digital Channels (on 54621D and 54622D only)
Max Sample Rate 400 MSa/s
Max Memory Depth 8 MB
Vertical Resolution 1 bit
Glitch Detection (min pulse width) 5 ns
service.book Page 9 Wednesday, December 18, 2002 8:35 AM
