Agilent Technologies 54624A User Manual

2-9
Front-Panel Overview
54620/40-series Oscilloscope Front Panels
Figure 2-3
54621D, 54622D, 54641D, and 54642D Mixed-Signal Oscilloscopes Front Panel
Display
Horizontal
controls
Trigger
controls
Run
controls
Intensity
control
Power
switch
Analog Channel
inputs/ controls
Probe
Comp
output
Floppy
disk
Softkeys
Waveform
keys
Measure
keys
File
keys
Entry
knob
Autoscale
key
Utility
key
Digital Channel
inputs/ controls
