13
5. Measure the voltage across the monitor resistor and across the input terminals, then calculate the Electronic Load
resistance. The result should be between:
6060B: 0.0416 and 0.0584 ohms.
6063B: 0.792 and 1.208 ohms.
c. Check the middle ohms range as follows:
1. Press:
6060B:
Range 10 Enter, thenRES 30Enter
.
6063B:
Range 25 Enter, thenRES 500Enter
.
2. Set power supply for:
6060B: 10.9V and 15A.
6063B: 44V and 4A.
3. Measure the voltage across the monitor resistor and across the input terminals, then calculate the Electronic Load
resistance. The result should be between:
6060B: 24.1 and 39.6 ohms.
6063B: 433 and 590 ohms.
4. Then press:
6060B:
RES 1 Enter
.
6063B:
RES 24Enter
.
5. Measure the voltage across the monitor resistor and across the input terminals, then calculate the Electronic Load
resistance. The result should be between:
6060B: 0.989 and 1.011 ohms.
6063B: 23.75 and 24.25 ohms.
d. Check the high ohms range as follows:
1. Press:
6060B:
Range 1001 Enter, thenRES 120Enter
.
6063B:
RES 120 Enter, thenRES 2000Enter
.
2. Set power source for:
6060B: 60V and 6A.
6063B: 240V and 2A.
3. Measure the voltage across the monitor resistor and across the input terminals, then calculate the Electronic Load
resistance. Calculation should be between:
6060B: 61.1 and 3243 ohms.
6063B: 1247 and 5037 ohms.
4. Then press:
6060B:
RES 12Enter
.
6063B:
RES 240Enter
.
5. Measure the voltage across the monitor resistor and across the input terminals, then calculate the Electronic Load
resistance. The result should be between:
6060B: 10.9 and 13.3 ohms.
6063B: 223 and 259 ohms.
