PERFORMANCE TEST RECORD - Agilent 6060B ELECTRONIC LOAD (Page 2 of 2)
Model Agilent 6060B Report No.____________________ Date______________________________
Test Description Minimum
Specification
Results Maximum
Specification
Measurement
Uncertainty
CONSTANT CURRENT MODE TESTS
60 Ampere Range Programming
and Readback
High Current (60A) 59.865 ____________A 60.135 25mA
Front Panel Display A
OUT
-0.095 ____________A A
OUT
+0.095 25mA
Low Current (1A) 0.924 ____________A 1.076
427µA
Front Panel Display A
OUT
-0.065 ____________A A
OUT
+0.065
427µA
6 Ampere Range
Programming and Readback
High Current (6A) 5.919 ____________A 6.081 2.4mA
Front Panel Display A
OUT
-0.068 ____________A A
OUT
+0.068 2.4mA
Low Current (1A) 0.924 ____________A 1.076
427µA
Front Panel Display A
OUT
-0.065 ____________A A
OUT
+0.065
427µA
CONSTANT VOLTAGE MODE TESTS
Voltage Programming and
Readback
High Voltage (60V) 59.890 ____________V 60.110
845µV
Front Panel Display V
OUT
-0.075 ____________V V
OUT
+0.075
845µV
Low Voltage (3V) 2.947 ____________V 3.053
35µV
Front Panel Display V
OUT
-0.046 ____________V V
OUT
+0.046
35µV
CONSTANT RESISTANCE MODE TESTS
Low Resistance Range
Resistance (1 Ω)
0.984
____________Ω
1.016
Resistance (0.05Ω)
0.0416
____________Ω
0.0584
Middle Resistance Range
Resistance (30Ω)
24.1
____________Ω
39.6
Resistance (1 Ω)
0.989
____________Ω
1.011
High Resistance Range
Resistance (120Ω)
61.1
____________Ω
3243
Resistance (12Ω)
10.9
____________Ω
13.3
TRANSIENT SLEW TEST
Fast Slew Transient
Slew Rate 0.05 A/µs
60
____________µs
100
Slew Rate 2.5 A/µs
1.2 ____________ms 2.0
CONSTANT CURRENT PARD TEST
Current (10A) 0 __________mA 4mA RMS
